1124 Nidec 1/5 hp 1075 RPM 208-230V 5.0″ Dia. (No Base) 1-Speed Open Fan Motor

• 1/5 hp 1075 RPM, 1 speed 1.3 amps 208-230V Volts 60 Hz PSC Motor
• 5.0″ Dia. Frame, Rolled Steel, Flat Shaft 5 5/8″ x 1/2″ x 5 5/8″

• Service Factor = 1, Overload Protection: Auto
• Hub Mount, Sleeve Bearings, Class B Insulation, CW Lead End
• 1 Year Manufacture Warranty

Direct Drive Fan Motor for central HVAC systems. Wiring diagram on motor name plate. Open, K0480TP1124673B
