ARB2024L1 Century 1/4 hp 1725 RPM 2-SPD 56Z Frame 115V Belt Drive TEAO Blower Motor Ball Brg Century # ARB2024L1

• 1/4 – 1/12 hp 1725/1140 RPM, 4.4/3.0 amps, 115 Volts 60 hz.
• 2-Speed
• Resilient Cradle Base
• Shaft 1/2″ x 1 5/8″
• 3.5″ Shaft Height
• 56Z Frame
• Rotation – Reversible
• Ball Bearings
• Automatic Overload Protection
• TEAO – Totally Enclosed Air Over
• Service Factor 1.0
• Motor case length 9 3/8″
• Extended thru bolts shaft end
• Includes 5/8″ shaft bushing
• Split phase motor
• 1 Year Manufacture Warranty.

Continuous Duty, Quick Connect Terminals, Easy Rotation Change, Class B Insulation.
Dayton 5DVT9
S56ASA43A01
