Z630 Washdown DC Permanent Magnet 1/4 HP

Product Description

Z630 Washdown DC Permanent Magnet 1/4 HP
Applications: Used in applications requiring regular washdown, such as in food processing plants, or in otherwise wet or humid enviroments in a variety of commercial and industrial applications such a conveyors, door openers, feeders and pumps
Features: Class F Insulation, NEMA C-Face with removable rigid base, Oversized brushes for extra long life, Doubled sealed, oversized ball bearings, Corrosion resistant 303 stainless steel shaft, “V” ring Forsheda seals, High temperature, moisture resistant lubricant, Exterior and interior components protected with enamel & polyester compounds, Aluminum conduit box, threaded and gasketed, Drains at 3:00, 6:00, 9:00 and 12:00 locations, Sealed machine fits, Stainless steel nameplate, USDA approved white epoxy paint, UL Recognized and CSA Certified
1/4 HP
1750 RPM
90 VC Volts
56C Frame
TENV Enclosure
2.7 Amps
Cross Reference:56E17V2001
